Product Description

New-Generation 1U 2-Socket Rack Server

The FusionServer 1288H V5 is a 1U, 2-socket rack server. It is ideal for high-density deployment to process workloads generated by
cloud computing virtualization, HPC, and big data processing. It delivers superior performance and excellent scalability while
improving space utilization in data centers, driving down the overall expenditure.

⭐️Superior Performance, Ultra-high Density

⭐️Smart Power Savings and Better Energy Efficiency

⭐️Unmatched Intelligent Manageability and Openness

Product Paramenters

MODEL	1288H V5
Processor	1 or 2 1st Generation Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 series), up to 205 W 1 or 2 2nd Generation Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 series), up to 205 W
Memory	24 DDR4 DIMM slots, 2933 MT/s; up to 12 Intel® Optane™ PMem modules (100 series), 2666 MT/s
Raid	RAID 0, 1, 10, 5, 50, 6, or 60 Configured with a supercapacitor for power-off protection for the cache (optional) RAID level migration, drive roaming, self-diagnosis, and web-based remote configuration
Local Storage	Supports hot-plug hard drives and the following configuration options: 10 x 2.5-inch hard drives (6–8 NVMe SSDs and 2–4 SAS/SATA drives, with a total number of 10 or less) 10 x 2.5-inch SAS/SATA/SSDs (2–4 NVMe SSDs and 6–8 SAS/SATA HDDs, with a total number of 10 or less) 10 x 2.5-inch SAS/SATA/SSDs 8 x 2.5-inch SAS/SATA hard drives 4 x 3.5-inch SAS/SATA hard drives Flash storage: 2 M.2 SSDs
Power Supply	2 hot-swappable PSUs with support for 1+1 redundancy and the following configuration options: 550W AC Platinum PSUs 900W AC Platinum/Titanium PSUs 1,500W AC Platinum PSUs 1,500W 380V HVDC PSUs 1,200W -48V to -60V DC PSUs
Sizing	Chassis with 3.5-inch hard drives: 43 mm x 447 mm x 748 mm (3.39 in. x 17.60 in. x 29.45 in.) Chassis with 2.5-inch hard drives: 43 mm x 447 mm x 708 mm (3.39 in. x 17.60 in. x 27.87 in.)
Outline specification	1U rack server
Ports/PCIE	Up to 5 PCIe 3.0 slots, including 1 for a RAID controller card and 1 for a flexible NIC
Supported operating systems	Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux, Ubuntu, Debian, openEuler, etc .
Warranty	3years

Product packaging

Fast shipping within 3-7 days Multiple transportation options for you to choose from Face to face delivery, supporting inspection
Please contact me to inform you of your needs, and I will reply to you within 5 minutes!!

Main Products

We will serve your every need by providing a full range of products and services from supply to design ,engineering , training ,maintenace and development.

Company Profile

FAQ

1. Who are we?

We are based in Beijing, China, start from 2019, sell to Domestic Market(00.00%). There are total about 11-50 people in our office.

2. How can we guarantee quality?

Always a pre-production sample before mass production; Always final Inspection before shipment;

3.What can you buy from us?

Workstion ,computer ,server

4. Why should you buy from us not from other suppliers?

We have nearly 20 years of experience in the server industry

5. What services can we provide?

Accepted Delivery Terms: FOB,CIF,CIP,DDP,Express Delivery;

Accepted Payment Currency:USD,EUR,HKD,CNY;

Accepted Payment Type: T/T,L/C,Western Union;

Language Spoken:English,Chinese

Back Home Page

Product Description

ThinkSystem Lenovo SR868 Rack Server

ThinkSystem Lenovo SR868 Rack Server 4U Rack Server Stable high-speed Flexible design Support remote Critical business applications

⭐️Advanced scalability&flexibility

High speed database processing and business analysis

⭐️Excellent performance The Intel Xeon series processor family provides real-time analysis, critical business processing, and big data insight. Excellent data center efficiency and recognized reliability to handle any workload

⭐️Memory high operation

16G/32G/64G memory capacity available for selection

48 memory slots per computing module, with a full load capacity of up to 6T and high-speed DDR42666MHz memory

Can quickly expand business and analyze big data

⭐️Massive storage first Advanced storage configuration Choose flexible storage configurations for workload optimization performance The SR868 enclosure supports up to 16 2.5-inch hard drive bays

⭐️Efficient heat dissipation Multiple fan combinations for efficient heat dissipation can help servers maintain low operating temperatures during operation

Product Paramenters

MODEL	Lenovo SR868 server
Processor	2 or 4 second-generation Intel ® xeon ® Scalable processor platinum series, up to 205W
Memory	up to 6TB in 48 sockets,using 128GB DIMMs; 2666MHz/2933MHz (planned support)TruDDR4
Storage controllers	Hardware RAID (up to 16 ports) with flash memory cache; up to 16 port HBAs
Drive Bay	Up to 16 2.5 inch storage bays supporting SAS/SATA HDDs and SSDs, or 8 2.5 inch NVME SSDs;And 2 mirrors M.2 start
Power Supply	2 hot plug/redundant:750W/1100W/1600W/2000 AC 80 PLUS platinum power supply
Sizing	482mm*766mm"175mm
Outline specification	4U rack server
Ports/PCIE	Ports: Multiple options of 1GbE,10GbE,25GbE,32GbE,40GbE or lnfiniBand PCle adapters are provided; 1(2/4 ports)1GbEor 10GbE LOM card PCIE: Up to 13 PCles are supported,including 1 LOM interface; Optional 1 ML2 interface
Supported operating systems	Microsoft,Red Hat,SUSE,VMware
Warranty	3years
Configuration	ThinkSystem SR868, 2* 5117 2.0GHz 14C, 232GB DDR4, 48 DIMMs,8x2.5" disk slots 730-8i 1GB,41000M, 2*1100W, NO DVD,4U Chassis

Product packaging

Fast shipping within 3-7 days Multiple transportation options for you to choose from Face to face delivery, supporting inspection
Please contact me to inform you of your needs, and I will reply to you within 5 minutes!!

Main Products

We will serve your every need by providing a full range of products and services from supply to design ,engineering , training ,maintenace and development.

Company Profile

FAQ

1. Who are we?

We are based in Beijing, China, start from 2019, sell to Domestic Market(00.00%). There are total about 11-50 people in our office.

2. How can we guarantee quality?

Always a pre-production sample before mass production; Always final Inspection before shipment;

3.What can you buy from us?

Workstion ,computer ,server

4. Why should you buy from us not from other suppliers?

We have nearly 20 years of experience in the server industry

5. What services can we provide?

Accepted Delivery Terms: FOB,CIF,CIP,DDP,Express Delivery;

Accepted Payment Currency:USD,EUR,HKD,CNY;

Accepted Payment Type: T/T,L/C,Western Union;

Language Spoken:English,Chinese

Back Home Page

Place of Origin:	China

Price:	$1,200/pieces 1-9 pieces
Packaging Details:	Carton Box
Delivery Time:	15 work days

Processor Type:	Intel Xeon	Type:	Rack
Model Number:	1288HV5	Brand Name:	XFUSION
Place Of Origin:	China	Products Status:	Stock
Product Name:	1288H V5	Processor:	3100/4100/5100/6100/8100 Series
Memory:	32G	Hard Drive:	3.84T
Power Supply:	500W	Raid Card:	H755
Warranty:	3 Years	Condition:	Brand New
Leading Time:	1-3 Working Days
Highlight:	2 Socket 1U Rack Server , 32G Memory 1U Rack Server , 32G Memory X Fusion Server

32G Memory 1U Rack Server X Fusion Server 1288H V6 Stock Generation 2 Socket
